Tubes, Hoses, Bellows

Tubing

Fluoropolymer tubes offer outstanding chemical, heat, and weather resistance. They are used for fluid transfer in a wide range of fields, such as electronics including semiconductors and liquid crystals, medical and food fields, and fine chemicals.

Product Code	Product Name	Description	Application	Data Sheet
Tombo No. 9003	NAFLON™ tube	PTFE, PFA, FEP	Basic	N/A
Tombo No. 9003-PFA-HG	NAFLON™ PFA-HG tube	Chemical transportation	Semiconductor	N/A
Tombo No. 9003-BT	NAFLON™ BT	+ Bend without buckle + More transparent than normal PTFE Tubing	Industrial	N/A
TomboNo. 9003-PFA-NE	NAFLON™ PFA-NE tube	Outside surface conductivity	Semiconductor	N/A
Tombo No. 9003-PFA-AS	NAFLON™ PFA-AS tube	Inside and outside surface conductivity	Semiconductor	N/A
Tombo No. 9003-RPL	NAFLON™ RPL tube	Flexible, small bend radius	Industrial	N/A
Tombo No. 9055	NAFLON™ Bent tube	PFA, PTFE preformed shapes	Semiconductor	N/A

TOMBO™ No. 9003-PTFE/PFA/FEP NAFLON™ PTFE/PFA/FEP TUBE

PTFE/PFA/FEP tube

TOMBO™ No. 9003-PTFE/PFA/FEP

NAFLON™ PTFE/PFA/FEP TUBE

NAFLON tubes are pure fluororesin tubes that do not include additional agents such as fillers and plasticizers. PTFE, PFA, and FEP all have excellent chemical resistance, heat resistance, and weather resistance.

Forte

It has excellent non-adhesive properties, with little affixing of dirt or scale.
It experiences very little drop in its electrical properties at high temperatures, high humidity, and high frequencies, and so it is perfect for electrical insulation applications.
It has excellent weather resistance and does not degrade even if used outside for long periods.

Others

TOMBO is a registered trademark or trademark of NICHIAS Corporation.
Name of products with "®" are registered trademarks of NICHIAS Corporation.
Name of products with "™" are trademarks of NICHIAS Corporation

Download catalog

TOMBO™ No. 9003-BT NAFLON™ BT TUBE

Bendable, buckling-resistant tube

TOMBO™ No. 9003-BT

NAFLON™ BT TUBE

NAFLON BT Tube is a type of PTFE tube. It has better flexibility and transparency than other PTFE tubes. As it bends easily and is not susceptible to buckling, it is suitable for pipes installed in tight spaces.

Forte

It bends easily and is not susceptible to buckling even at small bending radii.
It has excellent transparency compared to regular PTFE tubes.

Others

TOMBO is a registered trademark or trademark of NICHIAS Corporation.
Name of products with "®" are registered trademarks of NICHIAS Corporation.
Name of products with "™" are trademarks of NICHIAS Corporation

Download catalog

TOMBO™ No. 9003-PFA-HG NAFLON™ PFA HG TUBE

PFA tube for chemical transportation

TOMBO™ No. 9003-PFA-HG

NAFLON™ PFA HG TUBE

The NAFLON PFA-HG Tube is a PFA tube that uses New PFA material with little fluorine ion elusion and achieves a smooth inner tube surface by controlling the higher-order structure of PFA (grain refinement of spherulites). It is best suited to applications in semiconductor and liquid crystal industrial fields that require improved cleanliness.

Forte

In addition to conventional PFA tube performance, it has the following features:

It has a smooth inner tube surface (Rt = 0.2μm*).

Reduced particle and chemical solution residue
Reduced cleaning up (cleaning time)
Reduced chemical solution ingress due to a smaller inner surface volume of the tube
Increased transparency
Increased dielectric strength
*These values are our actual measurement values. They are not standard values.

It uses a new-PFA raw material.

Reduced fluorine ion elution
Improved stress crack resistance in stress environments
(e.g. piranha solution, oleum)

Product specification

In millimeter

Nominal dimensions (mm)	Outside diameter (mm)		Thickness (mm)		Length (m)
Inside diameter x Outside diameter	Standard dimensions	Tolerance	Standard dimensions	Tolerance	Standard dimensions	Tolerance
2×4	4.0	±0.10	1.0	±0.06	10,50	+1% -0%
3×4	4.0		0.5	±0.05
4×6	6.0		1.0	±0.06
6×8	8.0	±0.12	1.0	±0.06
8×10	10.0		1.0	±0.06
10×12	12.0		1.0	±0.06
16×19	19.0		1.5	±0.10
22×25	25.0	±0.15	1.5	±0.10

*Please confirm the delivery date (availability of stock).

The burst pressure at room temperature and the minimum bending radius are the same as the NAFLON PFA Tube.

Size in inches

In millimeter

Nominal dimensions (mm)	Outside diameter (mm)		Thickness (mm)		Length (m)
Inside diameter x Outside diameter	Standard dimensions	Tolerance	Standard dimensions	Tolerance	Standard dimensions	Tolerance
2.17×3.17	3.17	±0.10	0.50	±0.05	10,50	+1% -0%
3.96×6.35	6.35		1.20	±0.10
4.35×6.35	6.35		1.00	±0.06
6.35×9.52	9.52	±0.12	1.59	±0.10
7.52×9.52	9.52		1.00	±0.06
9.52×12.70	12.70		1.59	±0.10
15.88×19.05	19.05		1.59	±0.10
22.22×25.40	25.40	±0.15	1.59	±0.10

Please confirm the delivery date (availability of stock).
The burst pressure at room temperature and the minimum bending radius are the same as the NAFLON PFA Tube.

Others

TOMBO is a registered trademark or trademark of NICHIAS Corporation.
Name of products with "®" are registered trademarks of NICHIAS Corporation.
Name of products with "™" are trademarks of NICHIAS Corporation

Download catalog

TOMBO™ No. 9003-PFA-AS NAFLON™ PFA AS TUBE

PFA tube with anti-static inner and outer surfaces

TOMBO™ No. 9003-PFA-AS

NAFLON™ PFA AS TUBE

The NAFLON PFA-AS (Anti-Static) Tube is a PFA-HG tube that has a striped conductive PFA part on the inside and outer layer.
It is a tube where the fluid inside is visible and it can prevent tube insulation breakdown due to transferring the likes of organic solvents, fuels, refrigerants, powders, and steams.

Forte

It has chemical resistance, heat resistance, and weather resistance equivalent to that of a PFA tube.
It has an antistatic feature and can prevent the dielectric breakdown of the tube due to triboelectrification with fluids.
The fluid inside is visible.

Quality Characteristics

In millimeter

Nominal dimensions (mm)	Outside diameter (mm)		Thickness (mm)		Length (m)
Inside diameter x Outside diameter	Standard dimensions	Tolerance	Standard dimensions	Tolerance	Standard dimensions	Tolerance
4×6	6.0	±0.15 -0.10	1.0	±0.10	10,50,100	+1% -0%
6×8	8.0		1.0
8×10	10.0		1.0
10×12	12.0	±0.25 -0.10	1.0
16×19	19.0		1.5	±0.15
22×25	25.0		1.5	±0.15

Conductive PFA part

Nominal dimensions (mm)	Internal circumference				Outer circumference				The thick part		Number of stripes
Inside diameter x Outside diameter	Thickness (mm)		Width (mm)		Thickness (mm)		Width (mm)		Width (mm)
	Standard dimensions	Tolerance	Standard dimensions	Tolerance	Standard dimensions	Tolerance	Standard dimensions	Tolerance	Standard dimensions	Tolerance
4×6	0.02	+0.18 -0.015	1.4	±0.5	0.02	+0.18 -0.015	2.1	±0.5	0.02	+0.18 -0.015	4
6×8			2.1	±0.7			2.8	±0.9
8×10			2.8	±0.9			3.5	±1.1
10×12			1.3	±0.6			2.2	±0.8			8
16×19			2.0	±0.8			3.2	±1.0
22×25			2.7	±1.0			4.4	±1.4

Size in inches

Nominal dimensions (mm)	Outside diameter (mm)		Thickness (mm)		Length (m)
Inside diameter x Outside diameter	Standard dimensions	Tolerance	Standard dimensions	Tolerance	Standard dimensions	Tolerance
3.96×6.35	6.35	+0.15 -0.10	1.20	±0.12	10,50,100	+1% -0%
4.35×6.35	6.35		1.00	±0.10
6.35×9.52	9.52		1.59	±0.15
7.52×9.52	9.52		1.00	±0.10
9.52×12.70	12.7	+0.25 -0.10	1.59	±0.15
15.88×19.05	19.0		1.59
22.22×25.40	25.4		1.59

Conductive PFA part

Nominal dimensions (mm)	Internal circumference				Outer circumference				The thick part		Number of stripes
Inside diameter x Outside diameter	Thickness (mm)		Width (mm)		Thickness (mm)		Width (mm)		Width (mm)
	Standard dimensions	Tolerance	Standard dimensions	Tolerance	Standard dimensions	Tolerance	Standard dimensions	Tolerance	Standard dimensions	Tolerance
3.96×6.35	0.02	+0.18 -0.015	1.6	±0.5	0.02	+0.18 -0.015	2.3	±0.5	0.02	+0.18 -0.015	4
4.35×6.35
6.35×9.52			2.2	±0.7			3.4	±0.9
7.52×9.52											8
9.52×12.70			1.2	±0.6			2.3	±0.8
15.88×19.05			2.0	±0.8			3.2	±1.0
22.22×25.40			2.6	±1.0			4.3	±1.4

For the burst pressure at room temperature and the minimum bending radius, see PTFE/PFA/FEP Tube.
*Please confirm the delivery date (availability of stock).
*If you would like to request other sizes, please contact us.

Others

TOMBO is a registered trademark or trademark of NICHIAS Corporation.
Name of products with "®" are registered trademarks of NICHIAS Corporation.
Name of products with "™" are trademarks of NICHIAS Corporation

Download catalog

TOMBO™ No. 9003-NE NAFLON™ PFA NE TUBE

Anti-static PFA tube for chemical transportation

TOMBO™ No. 9003-NE

NAFLON™ PFA NE TUBE

The NAFLON PFA-NE (PFA: Tetrafluoroethylene Perfluoroalkoxy Ethylene Copolymer, NE: Non-Explosion) Tube is a tube in which the outer surface of Nichias’ PFA-HG (inner surface of smooth New PFA) Tube has a striped, conductive PFA part.
Due to the isolation benefits of the conductive PFA part, it is best suited to preventing fire accidents caused by the discharge of sparks from a combustible gas atmosphere onto the outer surface of the tube.
*Winner of the Plunkett Award
Plunkett Award: An award established in 1988 to mark the 50th anniversary of the discovery of fluororesin Teflon™ by Doctor Plunkett, a scientist of DuPont™.

Forte

Isolation benefits of the conductive PFA part:
･ It prevents spark discharge that can lead to igniting fires.
･ It prevents the dielectric breakdown of the tube due to discharge from within an electrical isolation atmosphere.
Benefits of the connection part being a PFA-HG tube:
･ There is little fluorine ion elution within the chemical solution.
･ There is little chemical solution permeation and residual.
･ It has chemical resistance, heat resistance, and strength equivalent to that of PFA.
Comparison in the case of preventing electrification by covering the PFA tube with a shielded conductor:
･ In comparison to covering with metal wire or a metallic mesh, there are no concerns over corrosion.
･ Reduces the time and effort of the covering work.
･ There is no danger of it being grounded due to inconsistency in the covering work.

Applications and usage precautions

Application
For transporting high-purity chemicals and gas in semiconductor production equipment, which uses organic solvents (stripper fluid, acetone, IPA, thinner, etc.) that can ignite easily.
For transporting high-purity chemicals and gas nearby electrical equipment that is susceptible to noise from static electricity.
Has a shielded conductor coating and can be used as a substitute for a PFA tube.

Precautions for use
Make sure that it is grounded before using. For grounding, Nichias has a dedicated conductivity Grounding Band available.

Grounding Band
Please contact us if you have any questions regarding using or choosing this product.
The part that comes into contact with liquid is a non-conductive PFA-HG tube, and so it is thought that it does not prevent dielectric breakdown from streaming electrification with the liquid.
When using the product for tubes of sizes outside the applicable scope, use two Grounding Bands.

Properties

Volume resistivity
Unit: (Ω･cm)

Material	Volume resistivity
Conductive PFA	5.3×10²
PFA-HG	10¹⁸

*Measurement method: Complies with JIS K 7194.
*The values above are our actual measurement values. They are not standard values.
Antistatic properties
Unit: (V)

Tube type	1-meter-length tube: center part	15-meter-length tube: center part	1-meter-length tube: other end
PFA-NE tube	0.5 to 0.7	0.5 to 0.7	0.5 to 0.7
PFA-HG Tube	2.0 (measurement limit)	-	-

*Measurement method: The edge is grounded, the 20 cm width of the center part or the other end is rubbed 50 times with Bemcot, and the surface potential at this part is measured.
*The values above are our actual measurement values. They are not standard values.

Standard dimension

Type	Nominal dimensions (mm)			Conductive part (mm) Thickness × width × quantity	Length	Burst pressure at 25°C (MPa)	Minimum bending radius (mm)
Type	Inside diameter	Outside diameter	Thickness	Conductive part (mm) Thickness × width × quantity	Length	Burst pressure at 25°C (MPa)	Minimum bending radius (mm)
	2	3	0.50	0.03 x 0.6 x 4	10 50 100	5.4	15
	2	4	1.00	0.06×0.8×4		8.3	15
	3	4	0.50	0.03×0.8×4		3.9	20
	4	6	1.00	0.06×1.4×4		5.4	25
	6	8	1.00	0.06×1.8×4		3.9	50
	8	10	1.00	0.06×2.3×4		2.9	80
	10	12	1.00	0.06×2.6×8		2.5	130
	16	19	1.50	0.06×3.8×8	10 50	2.4	200
	22	25	1.50	0.06×4.9×8	10 50	1.8	370
	2.17	3.17	0.50	0.03×0.6×4	10 50 100	5.3	15
	4.35	6.35	1.00	0.06×1.5×4		4.9	30
	6.35	9.52	1.59	0.06×2.4×4		5.4	40
	7.52	9.52	1.00	0.06×2.2×4		3.1	70
	9.52	12.70	1.59	0.06×2.6×8		4.1	75
	15.88	19.05	1.59	0.06×3.8×8	10	2.6	200
	22.22	25.40	1.59	0.06×4.9×8	50	1.9	370

*Burst pressure at 25°C: A tube sample 30 cm in length was pressurized with nitrogen gas at a rate of 0.1 MPa/min.
*Bending radius: Measured as per Nichias’ Minimum Bending Test Standard (AS5-6-0429).
*The values above are our actual measurement values. They are not standard values.

Others

TOMBO is a registered trademark or trademark of NICHIAS Corporation.
Name of products with "®" are registered trademarks of NICHIAS Corporation.
Name of products with "™" are trademarks of NICHIAS Corporation

Download catalog

TOMBO™ No. 9003-RPL NAFLON™ RPL TUBE

Flexible tube

TOMBO™ No. 9003-RPL

NAFLON™ RPL TUBE

NAFLON RPL Tube is a tube made by adding helix-shaped grooves to NAFLON PTFE Tube. It has outstanding flexibility, a small bending radius, low friction, and excellent non-adhesiveness. It is a tube with little fluid pressure loss and for which fluid is not susceptible to adhering to the inner tube walls.

Forte

It offers excellent flexibility.

Type

According to the application, there are two types of dimensions for the edges: the inside diameter standard (I) and the outside diameter standard (O).
Inside diameter standard tube (I) (A type only)
Use this when joining a pipe and so on to the inside of the tube. You can join either glass, metallic, or resin pipes.
Outside diameter standard tube (O) (A, B, C types)
Use this when using a tube joint, etc. For the shape of the tip, we offer three types of structure to suit your application.

A type
Straight at both ends

B type
With a reinforced sleeve at both ends

C type
Straight and welded at both ends

Quality Characteristics

Inside diameter of standard tube (I)

Nominal diameter	Inside diameter of edge (mm)	Helix outside diameter (mm)	Burst pressure at room temperature (MPa)	Minimum bending radius (mm)	Maximum manufacturing length (m)
6A	6	8.5	1.8	6.0	3.0
8A	8	10.5	1.4	7.0	3.0
10A	10	13.0	1.0	10.0	3.0
12A	12	16.0	0.9	15.0	3.0
15A (Note 1)	16	17.5	0.8	25.0	3.0
1/4B	6.4	8.5	1.8	6.0	3.0
3/8B	9.5	13.0	1.0	10.0	3.0
1/2B	12.7	16.0	0.9	15.0	3.0

Measurement organization: NICHIAS
Outside diameter of standard tube (O)

Nominal diameter	Outside diameter of edge (mm)	Helix outside diameter (mm)		Burst pressure at room temperature (MPa)		Minimum bending radius (mm)		Maximum manufacturing length (m)
Nominal diameter	Outside diameter of edge (mm)	A and B types	C type	A and B types	C type	A and B types	C type	Maximum manufacturing length (m)
6A	6	8.5		1.8		6.0		3.0
8A	8	9.5	10.5	1.6	1.4	7.0		3.0
10A	10	12.0	13.0	1.3	1.0	9.0	10.0	3.0
12A	12	14.5	16.0	1.0	0.9	10.0	15.0	3.0
1/4B	6.4	8.5		1.8		6.0		3.0
3/8B	9.5	12.0	13.0	1.3	1.0	9.0	10.0	3.0
1/2B	12.7	14.5	16.0	1.0	0.9	10.0	15.0	3.0

Measurement organization: NICHIAS
Note 1: For 15 A, the A-type edge shape is standard. Please contact us if you have any questions about other types.
*The dimensions of the inner diameter standard tube are those of the A-type. If you have any questions about models that are 3 meters or more in length, please contact us.
*The burst pressure and minimum bending radius at room temperature are actual measured values and are not standard values.
*For use in applications that experience repeated expansion or bending, please contact us.

Others

TOMBO is a registered trademark or trademark of NICHIAS Corporation.
Name of products with "®" are registered trademarks of NICHIAS Corporation.
Name of products with "™" are trademarks of NICHIAS Corporation

Download catalog

TOMBO™ No. 9065/9066/9067/9068 NAFLON™ HOSE

Fluoropolymer hose

TOMBO™ No. 9065/9066/9067/9068

NAFLON™ HOSE

NAFLON HOSE contains an inner hose made from an excellent heat- and chemical-resistant fluoropolymer. These products can be further modified to meet the requirements of particular applications by reinforcing the outside of the tube with protective stainless steel wire braiding or fitting with designated metal or flared connections. For its main applications, it is best suited as a pipe joint for steam, oil (particularly non-flammable oils), various gases, chemical solutions, and foodstuff.

Hose selection criteria
