Valve packings

Vendor: Update

Contact

Valve packing is a sealant that prevents fluid leaks from entering the stem and body of the valve, keeping it contained to the closed system.

Product Code	Product Name	Description	Application	Data Sheet
Tombo No. 2200, 2205	GRASEAL™ Packing	Expanded graphite	~ 400°C (in air; oxidizing atmosphere) ~ 1650°C (non- oxidizing atmosphere)	N/A
Tombo No. 2250	Low Torque Adapter	Lubricated graphite yarn	~ 400°C (in air; oxidizing atmosphere) ~ 600°C (non- oxidizing atmosphere)	N/A
Tombo No. 2930	High Guard Packing	Lubricated graphite yarn	~ 400°C (in air; oxidizing atmosphere) ~ 600°C (non- oxidizing atmosphere)	N/A
Tombo No. 2996-NA	Plastic Graphite Packing - NA	Special fibers + graphite + synthetic rubber	~ 200°C	N/A
Tombo No. 2280-S, 2280-S-SQ	Super Seal	Expanded graphite with SS 316L	~ 400°C (in air; oxidizing atmosphere) ~ 600°C (non- oxidizing atmosphere)	N/A
Tombo No. 9033, 9034	NAFLON™ Fiber Packing-T	100% PTFE fiber	~ 260°C	N/A
Tombo No. 9077	NAFLON™ Carbon Fiber	Carbon fiber yarn + PTFE dispersion	~ 300°C	N/A
Tombo No. 9041/ 9042	NAFLON™ Fiber Packing-G	NAFLON™ Fiber Packing-G	~ 260°C	N/A
Tombo No. 9042-OX	NAFLON™ Fiber Packing-G (OX)	Stretched + reinforced PTFE	~ 260°C	N/A
Tombo No. 2940	Graphite Fiber	Graphite fiber	~ 400°C	N/A
Tombo No. 2788-AF	AL-METAL Packing - AF	Crinkled aluminium foil + special lubricant + graphite	~ 550°C	N/A
