TOMBO™ No. 5625 FINEFLEX BIO™ Board

Forte

A product made of alkali earth silicate (AES) wool that does not apply to OPHSCS.
It is lightweight and has a low thermal conductivity, and so it displays excellent insulation performance.
Processed products can be manufactured.

Application

General high-temperature insulation
Lining material and backup material for insulating the ceilings of kilns and furnace walls
Expansion allowance filler for each part within a furnace
Gas sealing materials

Quality characteristics

Item		TOMBO No.
Item		5625-M	5625-A
Features		Minimal odor type	It offers excellent machinability
Color		White
Density (kg/m3)		250
Maximum heat resistant temperature (°C)		1300
Regular working temperature (°C)		1000
Bending strength (MPa)	Normal state	0.2	0.5
Heat shrinkage rate (%)	1000°C	1.2	0.9
Heat shrinkage rate (%)	1200°C	1.7	2.8
Ignition loss (%)		0.7	4.0
Chemical components		SiO2, CaO + MgO, other

*The values above are our actual measurement values. They are not standard values.
*Depending on the usage environment, the product may crack and warp at a temperature of 1100°C or more.
*Please use ventilation system to avoid gas and odors during the initial heating process.
When ordering, please inform us of your usage conditions.

Standard dimensions
